The world’s most bankable solar inverter brand

Founded in 1997, SUNGROW is the world’s most bankable solar inverter brand. Having a strong 29-year track record in the PV industry, it has deployed hundreds of GW worldwide, being the undisputed leader in the Commercial and Utility scale projects. Pioneer in research and development, having the largest R&D team in the industry, SUNGROW inverters power installations help to produce green and clean energy in more than 60 countries. The company holds a worldwide market share of more than 20% and offers a broad product portfolio in both 1000V and 1500V solar inverter categories covering grid and hybrid needs as well as addressing energy storage projects from a few KWh up to multiple MWH. SUNGROW is focused on its mission “Clean Power for All” being one of the most trustworthy brand when it comes to solar inverters and ESS.

Residential Hybrid

SH3.0/3.6/4.0/5.0/6.0RS

Max. PV input voltage: 600V
MPPT voltage range: 40 – 560 V
Independent MPP inputs: 2
PV strings per MPPT: 1/1
HIGH EXTREME LINE

DC 2 in 1 connection enabled
Anti-PID function, PID recovery function, IP66

view datasheet

SH5.0/6.0/8.0/10RT-20

Max. PV input voltage: 1000V
MPPT voltage range: 150 – 950 V
Independent MPP inputs: 2
PV strings per MPPT: 1/1 - 1/2
HIGH EXTREME LINE

DC 2 in 1 connection enabled
Anti-PID function, PID recovery function, IP66

view datasheet

Residential Grid

SG3.0/3.6/4.0/5.0/6.0RS

Max. PV input voltage: 600V
MPPT voltage range: 40 – 560 V
Independent MPP inputs: 2
PV strings per MPPT: 1
COMMERCIAL EXTREME LINE

DC 2 in 1 connection enabled
PID recovery function
IP66

view datasheet

SG5.0/6.0/7.0/8.0/10/12RT

Max. PV input voltage: 1100V
MPPT voltage range: 160 – 1000 V
Independent MPP inputs: 2
PV strings per MPPT: 1/1 - 2/1
COMMERCIAL EXTREME LINE

DC 2 in 1 connection enabled

PID recovery function
IP66

view datasheet

Commercial

SG33CX/SG40CX/SG50CX

Max. PV input voltage: 1100V
MPPT voltage range: 200 – 1000 V
Independent MPP inputs: 3/4/5
PV strings per MPPT: 2
Rated AC Voltage (V): 3/N/PE, 230/400V
COMMERCIAL EXTREME LINE

DC 2 in 1 connection enabled

PID recovery function
IP66

view datasheet

SG33CX-P2 & SG50CX-P2

Max. PV input voltage: 1100V
MPPT voltage range: 200 – 1000 V
Independent MPP inputs: 3/4/5
PV strings per MPPT: 2
Rated AC Voltage (V): 3/N/PE, 230/400V
COMMERCIAL EXTREME LINE

DC 2 in 1 connection enabled
PID recovery function
IP66

view datasheet

SG125CX-P2

Max. PV input voltage: 1100V
MPPT voltage range: 180 – 1000 V
Independent MPP inputs: 12
PV strings per MPPT: 2
Rated AC Voltage (V): 3/N/PE, 230/400V
COMMERCIAL EXTREME LINE

DC 2 in 1 connection enabled
PID recovery function
IP66

view datasheet

Utility

SG125HX

Max. PV input voltage: 1500V
MPPT voltage range: 500 – 1500 V
Independent MPP inputs: 6
PV strings per MPPT: 2
Rated AC Voltage (V): 3/PE, 800V
COMMERCIAL EXTREME LINE

DC 2 in 1 connection enabled
PID recovery function
IP66

view datasheet

SG350HX

Max. PV input voltage: 1500V
MPPT voltage range: 500 – 1500 V
Independent MPP inputs: 12
PV strings per MPPT: 2
Rated AC Voltage (V): 3/PE, 800V
HIGH EXTREME LINE

DC 2 in 1 connection enabled
Anti-PID function, PID recovery function, IP66

view datasheet

Smart Communication Box

SMART COMMUNICATION BOX

COM100E

Max. Number of Supported Inverters: 30
RS485, Ethernet and WiFi communication
Energy meter, meteo station, sensors support
Inverter batch parameter settings and firmware updates
PV-Plant maintenance via remote Web access for optimized OPEX
Local monitoring

view datasheet

Online Monitoring Platform

ONLINE MONITORING PLATFORM

iSolarCloud

Centralized power plant management, optimized OPEX
Flexible data access, Web portal and App, remote or local maintenance
Full log for trace and audit
Parameter setting, firmware updates, IV curve diagnosis, data analysis and automated reports
User-defined performance views, full plant supervision via muti-dimensional analysis

view datasheet
